Base Curb Weight (lbs) | 7398 |
Base Curb Weight (lbs) | 8146 |
Curb Weight - Front (lbs) | 4209 |
Curb Weight - Rear (lbs) | 3189 |
Gross Axle Wt Rating - Front (lbs) | 5200 |
Gross Axle Wt Rating - Front (lbs) | 5600 |
Gross Axle Wt Rating - Front (lbs) | 6000 |
Gross Axle Wt Rating - Front (lbs) | 6500 |
Gross Axle Wt Rating - Front (lbs) | 7000 |
Gross Axle Wt Rating - Front (lbs) | 7500 |
Gross Axle Wt Rating - Rear (lbs) | 12880 |
Gross Combined Wt Rating (lbs) | 30000 |
Gross Combined Wt Rating (lbs) | 34500 |
Gross Combined Wt Rating (lbs) | 35000 |
Gross Combined Wt Rating (lbs) | 39000 |
Gross Vehicle Weight Rating Cap (lbs) | 15000 |
Gross Vehicle Weight Rating Cap (lbs) | 16000 |
Gross Vehicle Weight Rating Cap (lbs) | 16500 |
Drivetrain | Four Wheel Drive |
Eighth Gear Ratio (:1) | 0.85 |
Fifth Gear Ratio (:1) | 1.52 |
First Gear Ratio (:1) | 4.62 |
Fourth Gear Ratio (:1) | 1.77 |
Reverse Ratio (:1) | 4.70 |
Second Gear Ratio (:1) | 2.92 |
Seventh Gear Ratio (:1) | 1.00 |
Sixth Gear Ratio (:1) | 1.28 |
Third Gear Ratio (:1) | 2.13 |
Trans Description Cont. | Automatic w/OD |
Trans Description Cont. Again | |
Trans Order Code | 44G |
Trans Power Take Off | Yes |
Trans PTO Access | Yes |
Trans Type | 10 |
Transfer Case Model | Electronic |
Transfer Case Power Take Off | Yes |
Axle Capacity - Front (lbs) | 7000 |
Axle Capacity - Front (lbs) | 7500 |
Axle Capacity - Rear (lbs) | 12880 |
Axle Ratio (:1) - Front | 4.10 |
Axle Ratio (:1) - Front | 4.30 |
Axle Ratio (:1) - Front | 4.88 |
Axle Ratio (:1) - Rear | 4.10 |
Axle Ratio (:1) - Rear | 4.30 |
Axle Ratio (:1) - Rear | 4.88 |
Axle Type - Front | Non-Independent |
Axle Type - Rear | Rigid Axle |
Spring Capacity - Front (lbs) | 5200 |
Spring Capacity - Front (lbs) | 5600 |
Spring Capacity - Front (lbs) | 6000 |
Spring Capacity - Front (lbs) | 6500 |
Spring Capacity - Front (lbs) | 7000 |
Spring Capacity - Front (lbs) | 7500 |
Spring Capacity - Rear (lbs) | 12880 |
Suspension Type - Front | Other |
Suspension Type - Rear | Leaf |
Displacement | 6.7 L/406 |
Displacement | 7.3 L/445 |
Engine Oil Cooler | None |
Engine Order Code | 99N |
Engine Order Code | 99T |
Engine Type | Intercooled Turbo Diesel V-8 |
Engine Type | Regular Unleaded V-8 |
Fuel System | Diesel Direct Injection |
Fuel System | Sequential MPI |
SAE Net Horsepower @ RPM | 330 @ 2200 |
SAE Net Horsepower @ RPM | 335 @ 3750 |
SAE Net Torque @ RPM | 468 @ 3750 |
SAE Net Torque @ RPM | 950 @ 1800 |
Brake ABS System | 4-Wheel |
Brake ABS System (Second Line) | 4-Wheel |
Brake Type | 4-Wheel Disc |
Disc - Front (Yes or ) | Yes |
Disc - Rear (Yes or ) | Yes |
Drum - Rear (Yes or ) | |
Front Brake Rotor Diam x Thickness (in) | 15.4 |
Rear Brake Rotor Diam x Thickness (in) | 15.8 |
Rear Drum Diam x Width (in) | |
Cold Cranking Amps @ 0? F (2nd) | 750 |
Cold Cranking Amps @ 0? F (Primary) | 750 |
Maximum Alternator Capacity (amps) | 190 & 160 |
Maximum Alternator Capacity (amps) | 250 & 150 |
Maximum Alternator Capacity (amps) | 250 & 160 |
